ΕΙΣΟΔΟΣ
| Number of MPP trackers | 1 |
|---|---|
| Max. input current (Idc max_inverter) | 175 A |
| DC input voltage range (Udc min – Udc max) | 580 – 1000 V |
| Feed-in start voltage (Udc start) | 650 V |
| MPP voltage range (Umpp min – Umpp max) | 580 – 930 V |
| Max. PV generator power (Pdc max) | 150 kWpeak |
| Max. input current PV1 (Idc max, PV1) | 100 A |
| Max. input current PV2 (Idc max, PV2) | 100 A |
| Max. short-circuit current PV1 (Isc max, PV1) | 125 A |
| Max. short-circuit current PV2 (Isc max, PV2) | 125 A |
| Max. short-circuit current inverter (Isc max, inverter) | 250 A |
| Max. power PV system PV1 (Pdc max,PV1) | 79 kWpeak |
| Max. power PV system PV2 (Pdc max, PV2) | 79 kWpeak |
| Number of DC connections PV1 | 1 |
| Number of DC connections PV2 | 1 |
| Max. AC fuse size rating | 355 A |
ΕΞΟΔΟΣ
| AC nominal output (Pac,r) | 100 kW |
|---|---|
| Max. output power (Pac max) | 100 kVA |
| AC output current (Iac nom) | 151,5A at 220Vac , 144,9A at 230Vac |
| Grid connection (Uac,r) | 3~ NPE 380/220 , 3~ NPE 400/230 V |
| AC voltage range (Umin – Umax) | 180 – 270 V |
| Frequency (fr) | 50 / 60 Hz |
| Frequency range (fmin – fmax) | 45 – 65 Hz |
| Total harmonic distortion | <3,0% |
| Power factor (cos φac,r) | 0 – 1 ind,/cap, |
ΓΕΝΙΚΑ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ
| Width | 1109 mm |
|---|---|
| Height | 755 mm |
| Depth | 346 mm |
| Weight | 103 kg |
| Weight incl. packaging | 121 kg |
| Degree of protection | IP65 |
| Protection class | 1 |
| Overvoltage category (DC / AC) 1) | 2 / 3 |
| Night-time consumption | 15W |
| Installation | Indoor and outdoor 4) |
| Ambient temperature range | -40°C – +65°C (optional AC-disconnect: from – 30 to + 65 °C) |
| Permitted humidity | 0 – 100 % |
| Max. altitude 2) | 4000 |
| Certificates and compliance with standards | VDE-AR-N 4105, VDE-AR-N 4110, IEC 62109-1/-2, IEC 62116, IEC 61727 R25, AS/NZS 4777, CEI 0-16, CEI 0-21, EN 50549-1/-2, VDE 0126-1-1* |
| Inverter topology | Transformerless |
| Cooling | Active cooling technology and double wall system |
| Interference emission class | B |
ΑΠΟΔΟΣΗ
| Max. efficiency (PV – grid) | 98,5 % |
|---|---|
| European efficiency (ηEU) | 98,2 / 97,7 / 97,3 (580Vdc / 800Vdc / 930Vdc) |
| η at 5% Pac,r 3) | 95,57 / 90,89 / 89,19 (580Vdc / 800Vdc / 930Vdc) |
| η at 10% Pac,r 3) | 97,32 / 95,55 / 93,75 (580Vdc / 800Vdc / 930Vdc) |
| η at 20% Pac,r 3) | 98,23 / 97,39 / 96,79 (580Vdc / 800Vdc / 930Vdc) |
| η at 25% Pac,r 3) | 98,33 / 97,70 / 97,27 (580Vdc / 800Vdc / 930Vdc) |
| η at 30% Pac,r 3) | 98,44 / 97,91 / 97,54 (580Vdc / 800Vdc / 930Vdc) |
| η at 50% Pac,r 3) | 98,49 / 98,19 / 98,02 (580Vdc / 800Vdc / 930Vdc) |
| η at 75% Pac,r 3) | 98,38 / 98,19 / 98,05 (580Vdc / 800Vdc / 930Vdc) |
| η at 100% Pac,r 3) | 98,21 / 98,05 / 97,91 (580Vdc / 800Vdc / 930Vdc) |
| MPP adaptation efficiency | 99,9 |
ΠΡΟΣΤΑΤΕΥΤΙΚΕΣ ΣΥΣΚΕΥΕΣ
| DC insulation measurement | Included |
|---|---|
| Overload behaviour | Operating point shift. Power limitation 5) |
| DC disconnector | Included |
| DC Reverse polarity protection | Included |
| Integral RCMU | Included |
| Overvoltage protection devices | Type 1 + 2 integrated, Type 2 optional 6) |
ΔΙΕΠΑΦΕΣ
| 6x digital in/out + 6x digital in | Programmable interface for ripple control receiver, energy management, load control Inputs: Voltage level low: min. 0V – max. 1.8V; high: min. 4,5V – max. 28,8V / Input resistance: 70kOhm Outputs: 5 Watt @ 12V in total for all six digital outputs when supplied internally in case of no load on the USB Port. 1A @ >12,5V to 24V per digital output when supplied externally by an external power supply but in total max. 3A integrated |
|---|---|
| Emergency stop (WSD) | Yes |
| Datalogger and web server | Included 7) |
| WLAN | Fronius Solar.web, Modus TCP Sunspec, Fronius Solar API (JSON) 7) |
| 2x RS485 | Modbus RTU Sunspec |
| USB (type A socket) | 1 A supply |
| Ethernet LAN RJ45 | 10/100Mbit; max. 100m Fronius Solar.web, Modbus TCP Sunspec, Fronius Solar API (JSON) |
AC ΣΥΝΔΕΣΗ
| Cable cross section | 70 – 240 mm² |
|---|---|
| Conductor material | Al; Cu |
| Connection terminals | Cable lug or V clamps |
| Single core option (single core cable) | Cable gland: 5 x M40 (10 – 28 mm) |
| Multi core option (multi core cable) | Cable gland: 1 x multi core connection Ø 16 – 61.4 mm + 1 x M32 (10 – 25 mm) |
| AC Daisy Chaining option (single core cable) | Cable gland: 10 x M32 (10 – 25 mm) |
DC ΣΥΝΔΕΣΗ
| Cable cross section | 25 – 95 mm² |
|---|---|
| Conductor material | Al; Cu |
| Connection terminals | Cable lug or V clamps, Cable gland: 6 x M40 |
